特點：
●體積?。?4x9.5mm）
●聲壓高（12V時≥85dB）
●消耗電流?。ā?5mA，9V2.7kHZ）
●安裝簡便（臥式插入焊接）
電性能參數(shù)
Model No | BCE-1327A |
Min Sound Pressure Level | 85dB at2.7KHZ at 12Vp-p at 10cm |
Operating Voltage | 3~25V |
Max Current Consumption | <15mA |
Resonant Frequency | 2.7±0.5KHz |
Capacitance at 120HZ | 12±30%nF |
Housing Material | PBT |
Operating Temperature | -20℃~+70℃ |
Storage Temperature | -30℃~+80℃ |
Weight | 1.2g |
