特點(diǎn)：
●體積小（9.6x9.6x5.5mm）
●聲壓高（5V時(shí)≥82dB）
●消耗電流（≤30mA，5V2.7kHZ）
●安裝簡便（編帶貼片焊接）
電性能參數(shù)
Model No | BCE-MD96055 |
Rated Voltage | 5V |
Min Sound Pressure Level | ≥82dB |
Operating Voltage | 4~7V |
Max Current Consumption | ≤30mA |
Resonant Frequency | 2.7±0.3KHZ |
Housing Material | PPS |
Operating Temperature | -30℃~+80℃ |
Storage Temperature | -40℃~+85℃ |
Weight | 1.1g |
