特點:
●體積?。?.5x8.5x3mm)
●聲壓高(3V時≥85dB)
●消耗電流(≤100mA,3.6V2.7kHZ)
●安裝簡便(編帶貼片焊接)
電性能參數(shù)
Model No | BCE-MX8530A | |
Rated Voltage | 3.6V | 5V |
Min Sound Pressure Level | 85dB | 85dB |
Operating Voltage | 2~4V | 4~7V |
Max Current Consumption | <100mA | <80mA |
Resonant Frequency | 2.7KHz | 2.7KHz |
Coil lmpedance | 16±3Ω | 31±4Ω |
Housing Material | LCP | |
Operating Temperature | -30℃~+80℃ | |
Storage Temperature | -40℃~+85℃ | |
Weight | 0.4g |
