Electrical performance parameters
Model No | BCE1240H9.5TR | |
Item | Unit | Specification |
Construction |
| Open |
Using method |
| Transmitter/Receiver |
Nominal Frequency | Hz | 40K |
S P L(0dB=0.002mbar) |
| >-70dB |
Sensitivity(0dB=10V/pa) | dB | Type 110(10Vp-p/30cm/square wave) |
Directivity |
| 75deg |
Input voltage | pF | 2300±25%@1KHz |
Capacitance | m | 0.2….6 |
Resonant impedance | V | 30Vp-p |
Operating Temperature | ℃ | -30….+85 |
Housing material |
| AL |
