特點：
●體積?。?9x4.5mm）
●聲壓高（3V時≥85dB）
●消耗電流（≤100mA，3.0V2.7kHZ）
●安裝簡便（編帶貼片焊接）
電性能參數(shù)
Model No | BCE-MX0945A | |
Rated Voltage | 3V | 5V |
Min Sound Pressure Level | 85dB | 85dB |
Operating Voltage | 2~5V | 4~7V |
Max Current Consumption | <100mA | <100mA |
Resonant Frequency | 2.7KHz | 2.7KHz |
Coil lmpedance | 16±3Ω | 30±4Ω |
Housing Material | LCP | |
Operating Temperature | -30℃~+80℃ | |
Storage Temperature | -40℃~+85℃ | |
Weight | 0.6g | |
