特點：
●體積?。?.2x5.2x3mm）
●聲壓高（3V時≥75dB）
●消耗電流（≤110mA，3V4kHZ）
●安裝簡便（編帶貼片焊接）
電性能參數(shù)
Model No | BCE-MX5030A-0304 |
Min Sound Pressure Level | 75dB at 4KHZ at 3Vo-p at 10cm |
Operating Voltage | 2~4V |
Max Current Consumption | <110mA |
Resonant Frequency | 4KHz |
Coil lmpedance | 12±3Ω |
Housing Material | LCP |
Operating Temperature | -30℃~+80℃ |
Storage Temperature | -40℃~+85℃ |
Weight | 0.15g |
